Heavy Duty Abrasive Cutting Machine For Sectioning manufacturer

Name: Heavy Duty Abrasive Cutting Machine For Sectioning
Brand: VISHAL OPTICAL WORKS
Price: 1 INR
Availability: InStock

Price 1.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Heavy Duty Abrasive Cutting Machine For Sectioning manufacturer Specification

Bonding
Resin Bonded

Grain Type
Aluminium Oxide or Silicon Carbide

Hardness
High, Suitable for Sectioning Hard Materials

Toughness
Heavy Duty, Industrial Grade

Material
Heavy Duty Steel Body

Type
Abrasive Cutting Machine

Motor Power
3 HP to 5 HP (220/415V AC, 50 Hz)

Clamping Arrangement
Rigid Vice for Workpiece Holding

Cooling System
Integrated Recirculating Water Cooling

Safety Features
Enclosed Cutting Chamber, Safety Interlocks

Finish
Powder Coated

Dimensions (L x W x H)
Approx. 850 mm x 600 mm x 1200 mm

Accessories
Standard Cutting Wheels, Coolant Tank, Tool Kit

Cutting Wheel Diameter
300 mm to 400 mm

Speed
2800 RPM (No Load)

Cutting Capacity
Up to 120 mm diameter (depending on model)

Operation
Manual/Automatic Feed Variant

Weight
Approx. 200 kg (varies with model)

Heavy Duty Abrasive Cutting Machine For Sectioning manufacturer Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Week

Delivery Time
1 Days

About Heavy Duty Abrasive Cutting Machine For Sectioning manufacturer

Heavy Duty Abrasive Cutting Machine For Sectioning

We are the prominent manufacturer, exporter and supplier of Heavy Duty Abrasive Cutting Machine For Sectioning. The offered machines are fabricated by our adroit and knowledgeable professionals using supreme class basic materials as per the set industry norms. Highly acknowledged for accurate dimensions, easy maintenance, corrosion resistance, smooth functioning and durability, these are few features of the these machines. This Heavy Duty Abrasive Cutting Machine For Sectioning is available in various specifications and can be custom designed as per the clients given specifications.

Standard Features:

Heavy duty sectioning machine for large cross sections, irregular components, in short time.
Cutting Wheel Swings also with the Oscillation movement for faster large sectioning than the Chop Type.
Heavy Duty motor is provided 15 HP 3 Phase.
Machine is covered with Powder Coated sheets or Stainless Steel sheets.
Specially designed Heavy Steel Vice to hold any kind of piece.
Absolute minimal deformation, cool & burn-free sample production.
Large and Effective coolant delivery with adjustable focused vains fitted on wheel guard.
Coolant Circulation System is provided with suitable filtering arrangement.
Double Light attachments system is provided for clean and accurate cutting of samples.
Large Viewing window to monitor the cutting operation.

Models:

AC15B
AC15XY
AC15SS
AC15D

Optional attachment:

Magnetic separator helps cleaning the coolant tank saving frequent cleaning operations.
Variable Speed AC Drive

Powerful Sectioning for Demanding Applications

Equipped with a 3 HP to 5 HP motor and a high-speed 2800 RPM drive, this abrasive cutting machine delivers efficient and precise sectioning of tough materials, including metals and alloys. Its heavy-duty steel structure guarantees long-term stability, making it a preferred choice for industrial and metallurgical laboratories requiring high-throughput materialographic cutting.

Enhanced Safety and Cooling Features

To protect both operator and equipment, the machine is fitted with an enclosed cutting chamber and safety interlocks. The integrated recirculating water cooling system controls temperature during cuts, reducing wear on the cutting wheel and maintaining specimen integrity. This ensures a safer, cleaner, and more reliable sectioning process.

Versatility and User-Friendly Operation

Designed for flexibility, this machine supports both manual and automatic feeds, catering to a variety of sectioning needs. The quick-release rigid vice clamping system offers secure and easy workpiece positioning, while standard accessories like cutting wheels and a coolant tank provide a complete, ready-to-use solution.

FAQs of Heavy Duty Abrasive Cutting Machine For Sectioning:

Q: How does the integrated water cooling system benefit cutting operations?

A: The integrated recirculating water cooling system maintains lower temperatures at the cutting interface, effectively reducing heat buildup. This not only prolongs the life of the cutting wheel but also helps preserve the structural integrity of the workpiece, especially when sectioning hard or heat-sensitive materials.

Q: What materials can this abrasive cutting machine section effectively?

A: The machine, with its heavy-duty steel body, high-power motor, and abrasive wheels made of aluminium oxide or silicon carbide, is specifically engineered to handle hard materials such as metals, alloys, and similar industrial-grade specimens. Its high hardness and toughness make it suitable for demanding sectioning jobs.

Q: When should I use the manual feed versus the automatic feed variant?

A: The manual feed variant is ideal for specialized tasks that require fine, incremental control or when sectioning smaller batches. The automatic feed option is better suited for repetitive or high-volume operations, ensuring uniformity, speed, and reduced operator fatigue.

Q: What is the process for securely clamping a workpiece during cutting?

A: A rigid vice clamping arrangement is provided for holding the workpiece. Simply position the specimen within the vice, adjust to fit the diameter (up to 120 mm depending on model), and tighten securely. This ensures the stability and accuracy of every sectioning cut.

Q: Where can this machine be installed for optimal performance and safety?

A: It is best installed on a stable, level surface in a well-ventilated industrial workshop or laboratory setting. The substantial weight (approximately 200 kg) and powder-coated finish enable rugged use. Ensure the electrical settings (220/415V, 50 Hz) match the available supply for safe operation.

Q: What are the advantages of using this heavy duty abrasive cutting machine?

A: Key benefits include high precision, durability, safety features, flexible operation modes, consistent performance with recirculating cooling, and the ability to handle a variety of hard materials. It is designed to meet the rigorous demands of industrial and laboratory material sectioning, enhancing productivity and quality of results.
